VersaUV LEF-12i Benchtop UV Flatbed Printer
-
MSRP
LEF-12i: $17,995 US*
* U.S. only. For Canada, Latin America and Caribbean pricing, please call (949) 727-2100, or contact an Authorized Roland DGA Dealer in your area.
-
LEASE PRICE
LEF-12i: $360 US**
** For 60 months, OAC
Apply Now
The VersaUV LEF-12i offers countless product customization and substrate possibilities, including printing directly on three-dimensional objects up to 3.94” thick.
Versatile, Flexible, Brilliant
With the magic of LEF-12i flatbed UV printing, you can print graphics and add stylish finishes to standard substrates as well as unique promotional items.
- Gloss ink option enables spot gloss or matte finishes, as well as highly unique embossed effects
- Print on three-dimensional objects with ECO-UV inks that image brilliantly and stretch around complex corners and curves
- Perfect for pens, smart phone covers, personalized awards, giftware and so much more
- Add White ink as a spot color or as a flood behind CMYK on dark backgrounds and clear materials
A Cool Machine for Customizing Hundreds of items
Using state-of-the-art UV-LED lamps, the LEF-12i is a low-heat, cool-running machine that combines with vibrant ECO-UV inks to print on the following materials:
Choose an LEF to Suit Your Budget and Your Business
 |
 |
 |
|
| VersaUV LEF-12i | VersaUV LEF2-200 | VersaUV LEF2-300 | |
| Maximum Print Area | 12" x 11" | 20" x 13" | 30”x 13” |
| Ink Configuration Options | CMYK + Gloss + White |
CMYK + Gloss + White CMYK + Primer + White CMYK + White + White |
CMYK + Clear (gloss) + Clear (gloss)+ White CMYK + Clear (gloss) + White+ Primer |
| Included RIP Software | Roland DG VersaWorks 6 |
Roland DG VersaWorks 6 | Roland DG VersaWorks 6 |
| Accessories |
BOFA air filtration system (optional) Rotary Rack cylindrical printing attachment (optional) |
||
| Ideal For | Short-run customization of USB drives, smart phone covers, photo frames and other small objects. | Short-run customization of small objects or medium-sized items, plus pre-primed printing onto various substrates and unique surfaces. | Volume production of small to medium-sized items, plus pre-primed printing onto various substrates and unique surfaces. |
New! Rotary Rack for Printing on Cylindrical Objects
The Rotary Rack option for LEF series flatbeds makes printing directly on cylindrical objects easier and more affordable than ever. A metal frame design and non-flex rollers ensure durability and consistent, high-quality results. With a superior design and simple set-up, you'll be printing and profiting in no time.
Additional Information
Brochure
Download Your VersaUV LEF Series Brochure
Get your digital guide to all the features, applications, benefits and specifications of the Benchtop UV Flatbed Printer.
Download BrochureSample Request
Specifications
| Model | VersaUV LEF-12i | |
|---|---|---|
| Printing method | Piezo ink-jet method | |
| Acceptable media | Width | Maximum 12.2 inches (310mm) |
| Length | Maximum 13.2 inches (335mm) | |
| Thickness | Maximum 3.94 inches (100mm) | |
| Weight | Maximum 11 lbs (5Kg) | |
| Printing Width | Maximum 12 inches (305mm) | |
| Printing Length | Maximum 11 inches (280mm) | |
| Ink cartridges | Type | ECO-UV 220ml cartridge |
| Colors | Six colors CMYK, White, Gloss | |
| Ink-Curing Unit | Built-in UV-LED lamp | |
| Print Resolution (dpi) | Maximum 1440 dpi | |
| Distance accuracy (when printing) *1 | Error of less than ±0.3% distance ±0.3mm, whichever is greater | |
| Connectivity | Ethernet (10Base-T/100Base-TX, automatic switching) | |
| Power-saving function | Automatic sleep feature | |
| Power requirements |
AC 100 to 240V ±10%, 1.8A (50/60Hz) | |
| Power Consumption | During operation | Approximately 149W |
| During standby | Approximately 13W | |
| Acoustic noise level | During operation | 60 dB (A) or less |
| During standby | 49 dB (A) or less | |
| Dimensions |
Width | 39.3 inches (998 mm) |
| Depth | 34.2 inches (867 mm) | |
| Height | 21.5 inches (546mm) | |
| Weight | 187.4 lb (85kg) | |
| Environment | During Operation *2 | Temperature:20 to 32°C or 68 to 90°F (22° or 72°F or higher is recommended) Humidity: 20 to 80% RH (no condensation) |
| Not operating | Temperature: 5 to 40°C or 41 to 104°F Humidity: 20 to 80% RH (no condensation) |
|
*2 Operating environment
| Roland VersaWorks 6 System Requirements | ||
| Operating system | Windows® 10 (32/64-bit) | |
| Windows® 8.1 (32/64-bit) | ||
| Windows® 7 Professional / Ultimate (32/64-bit) | ||
| CPU | Intel® Core™2 Duo, 2.0 GHz or faster recommended | |
| RAM | 2 GB or more recommended | |
| Video card and monitor | A resolution of 1,280 x 1,024 or more recommended | |
| Free hard-disk space | 40 GB or more recommended | |
| Hard-disk file system | NTFS format | |
| Optical drive | DVD-ROM drive | |
| Other requirements | Ethernet or USB port Internet connection and web browser to use Roland@NET |
|
Please note: Considering that you will be using software such as Illustrator, we recommend that you use as high performance computer as possible to reduce RIP processing time.
We also recommend using a hard disk that has large enough capacity, as print files are often tens of GB in size (or larger) when data is high resolution.
* Roland VersaWorks 6 is a 32-bit application, which runs on 64-bit Windows® with WoW64 (Windows 32-bit on Windows 64-bit).
