Texart XT-640 Dye Sublimation Printer
Strength and Style
Simply powerful sublimation printing.

Texart™ XT-640 Dye-Sublimation Printer

Developed specifically for dye-sublimation transfer printing, the Texart XT-640 is an unstoppable machine that delivers outstanding print quality on long print runs, day-after-day. By combining Roland DG reliability with the latest print technology, users can quickly and effortlessly create high-volume sportswear, fashion, soft signage, interior decoration, promotional merchandise and much more.

Request a Sample


Are you located in the United States, Canada, or Latin America?



Watch the XT-640 Overview

With its rugged construction and dual-print heads, the XT-640 Dye-Sublimation Printer is built to meet the most demanding production and quality requirements. It provides machine stability, a choice of ink configurations, including Fluorescent Pink (Fp) and Fluorescent Yellow (Fy), and is one of the fastest dye-sublimation printers on the market. Equipped with automatic ink-switching and iPad printer assist features, it also supports unattended printing on long print runs, even in high-speed modes.
Texart XT-640 close-up

Distinguishing Features

  • Durable and lasting build quality for long print runs and non-stop production
  • Dual-print heads increase production speed and maximize color quality with 7-droplet technology
  • 4-color high-speed printing or 8-color printing for wider color gamut and smooth color gradients
  • Roland DG Fluor Color Library offers hundreds of new colors with new Fluorescent Pink and Yellow inks
  • Automatic ink-switching and iPad printer assist for unattended printing
  • Error-free media alignment with new feed adjuster, take-up system and powerful vacuum



See The Texart XT-640 For Yourself

Built to effortlessly create high-volume sportswear, apparel, soft signage, interior decor, promotional merchandise and much more.

Print Error-Free with Advanced New Features

The XT-640 offers exceptional media tracking to prevent alignment errors during production. An advanced vacuum system keeps transfer paper flat for printing, while a convenient new feed adjuster and take-up system prevents media skewing and ensures a correctly wound roll for smooth transition to the heat transfer process.
2 Year Warranty
2 Year Warranty

Two-year warranty and unmatched reliability.

Roland DG has earned a worldwide reputation for building reliable machines and backing them up with unmatched customer service and technical support. The RT-640 is supplied with a Two-Year Trouble-Free Warranty and proudly displays all international ISO certifications as your confirmation of superior quality.

*Registration within 60 days purchase and continuous exclusive use of Roland DG inks during the first two years of ownership are required to qualify for the free second year of limited warranty coverage. See warranty page for details.

Additional Information

Expand All | Collapse All

To receive a free print sample from the Texart™ XT-640, complete the form below and click Submit.

Texart™ XT-640
Printing technology Piezoelectric inkjet
Media Width 10.2 to 64 in. (259 to 1,625 mm)
Thickness Maximum 39 mil (1.0 mm)
Roll outer diameter Maximum 8.3 in. (210 mm)
Roll weight Maximum 88 lbs. (40 kg)
Core diameter *1 3 in. (76.2 mm) or 2 in. (50.8 mm)
Printing width *2
 Maximum 63.6 in. (1,615 mm)
Maximum speed
(4-color 360x360 print mode)
 1,098 ft2/hr (102 m2/hr)
Ink
 Types Texart Ink (1 Liter pouches)
Colors 4-color (CMYK) and 8-color (Choose from CMYK+LcLmOrVi and CMYK+OrViFpFy options)

Available colors: cyan, magenta, yellow, black, light cyan, light magenta, orange, violet, fluorescent pink, and fluorescent yellow
Printing resolution (dots per inch) Maximum 1,440 dpi
Distance accuracy *3 Error of less than ±0.3 % of distance traveled, or ±0.3 mm, whichever is greater
Dryer *4 Setting range for the preset temperature: 30 to 55°C (86 to 131°F)
Connectivity Ethernet (100BASE-TX/1000BASE-T, automatic switching)
Power-saving function Automatic sleep feature
Power requirements AC 100 to 120V ±10%, 5.5 A, 50/60 Hz or AC 220 to 240V ±10%, 2.8A, 50/60 Hz
Power consumption During operation Approx. 750W
Sleep mode Approx. 70 W
Acoustic noise level During operation 62 dB (A) or less
During standby 45 dB (A) or less
Dimensions (with stand)) 111.7 (W) x 32.7 (D) x 65 (H) in.
(2,835(W) x 830(D) x 1,650 (H) mm)
Weight (with stand) 471.8 lb. (214 kg)
Environment Power on Temperature: 18 to 25°C (64.4 to 77°F)
Humidity: 35 to 65%RH (non-condensing)
Power off Temperature: 15 to 30°C (59 to 86°F)
Humidity: 20 to 80%RH (noncondensing)
Included items Exclusive stands, power cord, media clamps, media holder, replacement blade for separating knife, Software RIP, User's Manual, etc.

ErgoSoft Roland DG Edition System Requirements

Operating system Windows® 8/8.1 (32/64-bit); Windows® 7 Ultimate/Professional (32/64-bit); Windows Vista® Ultimate/Business (32/64-bit)
CPU Quadcore 2.5 GHz or faster recommended
RAM 4 GB or more recommended
Video card and monitor A resolution of 1,280 × 1,024 or more recommended
Free hard-disk space 40 GB or more recommended
Optical drive DVD-ROM drive

*1 The media holder for this machine is exclusively designed for media rolls with a paper tube measuring 3 inches in diameter. To use 2-inches media rolls, the optional media flanges are required.
*2 The length of the production run is subject to the limitations of the software program.

*3
  • Media type: Media specified by Roland DG Corp.
  • Temperature: 25°C (77°F), humidity: 50%
  • Roll media must be loaded correctly.
  • Excluding expansion/contraction of the media
  • All corrections or adjustment function of this machine have been made properly.
  • Print travel: 1 m
*4
  • Warm-up is required after the power is turned on. This may require 5 to 20 minutes, depending on the operating environment.
  • Depending on the ambient temperature and the media width, the set temperature may not be reached.
XT-640 Brochure

Download Your Texart XT-640 Brochure

Get your digital guide to all the features, applications, benefits and specifications of the Dye-Sublimation Printer.

Download Brochure
