Dye-Sublimation Transfer Printer | Texart RT 640 | Roland DGA
Texart RT-640 Dye-Sublimation Printer
Simply Brilliant
Exceptional dye-sublimation printing performance and value.

Save up-to $6,998.25* on a RT-640 with Section 179 Tax Deductions
 Calculate your Savings

*Estimated 35% Tax Bracket

Texart™ RT-640 Dye-Sublimation Transfer Printer

  • MSRP

    $19,995 US

    * Promotions valid in North and South America excluding Brazil. Pricing reflects US MSRP. Contact an Authorized Roland DGA Dealer in your area for details.

  • LEASE PRICE

    $420 US*

    ** For 60 months, OAC

    Apply Now

If you're looking to get into dye-sublimated soft-signage, apparel, décor, promotional goods and other highly profitable applications, then the RT-640 is the sublimation printing solution for you. Designed to combine superb quality, productivity and value with brilliantly simple operation, the advanced RT-640 Dye-Sublimation Transfer Printer is simply brilliant.

Request a Dealer

Presale Questions?

Chat is currently unavailable at this time. Please try again during our normal business hours, 7:00 AM - 5:00 PM PST.

Already Own a Roland?

Texart RT-640 Dye-Sublimation Printer

The Perfect Sublimation Printing Solution

The Texart RT-640 is a state-of-the-art device that fits effortlessly into sublimation printing workflows for productions ranging from fabric banners and branded apparel to promotional items and interior décor. Roland DG’s Texart solution includes the Texart printer, Texart inks, ErgoSoft Roland DG edition RIP software and options for accessories like transfer paper, making it easy for you to get into – or rev up – your sublimation business.
Texart RT-640 Dye-Sublimation Printer
Texart RT-640 Dye-Sublimation Printer

Brilliantly Simple Production

The RT-640 is designed for maximum ease-of-use. An automatic feed adjuster and media take-up system ensure even tensioning and prevent skewing of transfer paper, while a powerful vacuum keeps paper flat for printing. The result is precision details and a precisely wound roll at the take-up reel, ready for heat transferring. An innovative Roland DG Ink Switching System automatically switches to the backup ink pouch when the primary pouch runs out, providing up to 2000ml of ink per color in CMYK mode. Included ErgoSoft sublimation RIP software and Roland DG Printer Assist iPad app make it easy to manage operation.
Texart RT-640 Dye-Sublimation Printer
Texart SBL3 Ink

Brighten up Your Graphics with Texart SBL3 Ink

Achieve vivid colors, smooth gradations and super-sharp images with fast-drying Texart dye-sublimation inks. Specially formulated for Texart dye-sublimation printers, Texart ink delivers dense blacks, a wide color gamut that includes Orange and Violet ink options, and a high dye-concentration that reduces ink-limits without any reduction in color density or vibrancy. Texart SBL3 ink is also available in Fluorescent Pink and Yellow inks that produce hundreds of vivid fluorescent colors and soft pastel shades for fashionable sportswear, decor and eye-catching signs.
2 Year Warranty
2 Year Warranty

Two-year warranty and unmatched reliability.

Roland DG has earned a worldwide reputation for building reliable machines and backing them up with unmatched customer service and technical support. The RT-640 is supplied with a Two-Year Trouble-Free Warranty and proudly displays all international ISO certifications as your confirmation of superior quality.

*Registration within 60 days purchase and continuous exclusive use of Roland DG inks during the first two years of ownership are required to qualify for the free second year of limited warranty coverage. See warranty page for details.

Additional Information

Expand All | Collapse All
Texart™ RT-640
Printing technology Piezoelectric inkjet


Media
Width 10.2 to 64 in. (259 to 1,625 mm)
Thickness Maximum 39 mil (1.0 mm)
Roll outer diameter Maximum 8.3 in. (210 mm)
Roll weight Maximum 88 lbs. (40 kg)
Core diameter 1 3 in. (76.2 mm) or 2 in. (50.8 mm)
Printing width 2 Maximum 63.6 in. (1,615 mm)
Maximum speed
(4-color 360x360 print mode)
522 ft2/hr (48.5 m2/hr)
Ink pouches Types Exclusive sublimation ink pouch


Colors
4-color (CMYK) and 8-color (Choose from CMYK+LcLmOrVi and CMYK+OrViFpFy options) Available colors: cyan, magenta, yellow, black, light cyan, light magenta, orange, violet, fluorescent pink, and fluorescent yellow
Printing resolution (dots per inch) Maximum 1,440 dpi
Distance accuracy 3 Error of less than ±0.3% of distance traveled, or ±0.3 mm, whichever is greater
Connectivity Ethernet (10BASE-T/100BASE-TX, automatic switching)
Power-saving function Automatic sleep feature
Power requirements AC 100 to 240 V ±10%, 1.5 A, 50/60 Hz
Power consumption During operation Approx. 140 W
Sleep mode Approx. 31 W
Acoustic noise level During operation 62 dB (A) or less
During standby 49 dB (A) or less
Dimensions (with stand) 104.4 (W) x 31.3 (D) x 63 (H) in. (2,650 mm (W) x 795 mm (D) x 1,600 mm (H))
Weight (with stand) 353 lbs (160 kg)


Environment
Power on Temperature: 64.4 to 77° F (18 to 25° C), humidity: 35 to 65% RH (non-condensing)
Power off Temperature: 59 to 86° F (15 to 30° C), humidity: 20 to 80% RH (non-condensing)
Accessories Exclusive stands, power cord, media clamps, media holder, replace- ment blades for separating knife, User's Manual, etc.

ErgoSoft Roland DG Edition System Requirements

Operating system Windows® 8/8.1 (32/64-bit); Windows® 7 Ultimate/Professional (32/64-bit); Windows Vista® Ultimate/Business (32/64-bit)
CPU Quadcore 2.5 GHz or faster recommended
RAM 4 GB or more recommended
Video card and monitor A resolution of 1,280 × 1,024 or more recommended
Free hard-disk space 40 GB or more recommended
Optical drive DVD-ROM drive




1. The media holder of this machine is exclusive use for the media of paper tube (core) inner diameter 3 inches. To use 2 inches media, the optional media flanges are required.
2. The length of printing is subject to the limitations of the program.
3. • Media type: Media specified by Roland DG Corp.

• Temperature: 77°F (25°C), humidity: 50%

• Roll media must be loaded correctly.

• Excluding expansion/contraction of the media

• All corrections or adjustment function of this machine have been made properly.

• Print travel: 1 m

Download Your Texart RT-640 Brochure

Get your digital guide to all the features, applications, benefits and specifications of the Dye-Sublimation Transfer Printer.

Download Brochure

To receive a free print sample from the Texart RT-640, complete the form below and click submit.
