Texart™ RT-640 Dye-Sublimation Transfer Printer
* Promotions valid in North and South America excluding Brazil. Pricing reflects US MSRP. Contact an Authorized Roland DGA Dealer in your area for details.
** For 60 months, OACApply Now
If you're looking to get into dye-sublimated soft-signage, apparel, décor, promotional goods and other highly profitable applications, then the RT-640 is the sublimation printing solution for you. Designed to combine superb quality, productivity and value with brilliantly simple operation, the advanced RT-640 Dye-Sublimation Transfer Printer is simply brilliant.
The Perfect Sublimation Printing Solution
Brilliantly Simple Production
Brighten up Your Graphics with Texart SBL3 Ink
Two-year warranty and unmatched reliability.
Roland DG has earned a worldwide reputation for building reliable machines and backing them up with unmatched customer service and technical support. The RT-640 is supplied with a Two-Year Trouble-Free Warranty and proudly displays all international ISO certifications as your confirmation of superior quality.
*Registration within 60 days purchase and continuous exclusive use of Roland DG inks during the ﬁrst two years of ownership are required to qualify for the free second year of limited warranty coverage. See warranty page for details.
|Printing technology||Piezoelectric inkjet|
|Width||10.2 to 64 in. (259 to 1,625 mm)|
|Thickness||Maximum 39 mil (1.0 mm)|
|Roll outer diameter||Maximum 8.3 in. (210 mm)|
|Roll weight||Maximum 88 lbs. (40 kg)|
|Core diameter 1||3 in. (76.2 mm) or 2 in. (50.8 mm)|
|Printing width 2||Maximum 63.6 in. (1,615 mm)|
(4-color 360x360 print mode)
|522 ft2/hr (48.5 m2/hr)
|Ink pouches||Types||Exclusive sublimation ink pouch|
|4-color (CMYK) and 8-color (Choose from CMYK+LcLmOrVi and CMYK+OrViFpFy options) Available colors: cyan, magenta, yellow, black, light cyan, light magenta, orange, violet, fluorescent pink, and fluorescent yellow|
|Printing resolution (dots per inch)||Maximum 1,440 dpi|
|Distance accuracy 3||Error of less than ±0.3% of distance traveled, or ±0.3 mm, whichever is greater|
|Connectivity||Ethernet (10BASE-T/100BASE-TX, automatic switching)|
|Power-saving function||Automatic sleep feature|
|Power requirements||AC 100 to 240 V ±10%, 1.5 A, 50/60 Hz|
|Power consumption||During operation||Approx. 140 W|
|Sleep mode||Approx. 31 W|
|Acoustic noise level||During operation||62 dB (A) or less|
|During standby||49 dB (A) or less|
|Dimensions (with stand)||104.4 (W) x 31.3 (D) x 63 (H) in. (2,650 mm (W) x 795 mm (D) x 1,600 mm (H))|
|Weight (with stand)||353 lbs (160 kg)|
|Power on||Temperature: 64.4 to 77° F (18 to 25° C), humidity: 35 to 65% RH (non-condensing)|
|Power off||Temperature: 59 to 86° F (15 to 30° C), humidity: 20 to 80% RH (non-condensing)|
|Accessories||Exclusive stands, power cord, media clamps, media holder, replace- ment blades for separating knife, User's Manual, etc.|
ErgoSoft Roland DG Edition System Requirements
|Operating system||Windows® 8/8.1 (32/64-bit); Windows® 7 Ultimate/Professional (32/64-bit); Windows Vista® Ultimate/Business (32/64-bit)|
|CPU||Quadcore 2.5 GHz or faster recommended|
|RAM||4 GB or more recommended|
|Video card and monitor||A resolution of 1,280 × 1,024 or more recommended|
|Free hard-disk space||40 GB or more recommended|
|Optical drive||DVD-ROM drive|
|1.||The media holder of this machine is exclusive use for the media of paper tube (core) inner diameter 3 inches. To use 2 inches media, the optional media flanges are required.|
|2.||The length of printing is subject to the limitations of the program.|
|3.||• Media type: Media specified by Roland DG Corp.
• Temperature: 77°F (25°C), humidity: 50%
• Roll media must be loaded correctly.
• Excluding expansion/contraction of the media
• All corrections or adjustment function of this machine have been made properly.
• Print travel: 1 m
