NEW VersaUV LEF2-200 Benchtop UV Flatbed Printer
With optimized ease and efficiency, you can print directly onto accessories, giftware, ceramics, and countless other popular products. Create unique, desirable and highly-profitable custom items with the VersaUV LEF2-200 flatbed UV printer that offers brilliant color results, realistic textures and stylish embossed effects.
On-Demand Printing on One or Many Items
The Creative Possibilities of ECO UV Ink
Advanced Ink Printing
Print graphics with consistent color and incredible detail on a virtually unlimited range of promotional products.
- Produce stunning graphics with CMYK, White and Gloss ECO-UV® (EUV4) inks
- White ink acts as a brilliant spot color, or to ensure that colors pop on dark or clear substrates
- Optional Primer increases efficiency by prepping the surface of materials like acrylic and plastic for full-color customization*
- An Automated Ink Circulation System prevents ink pigments settling in the ink lines for smooth consistency and density
- Mist Filters catch the residual ink that mists off the edge of your media to prevent overspray and to keep ink from settling on internal components
* For best primer results, it is strongly recommended that users test for adhesion to specific substrates prior to final production.
A Convenient, Clean, and Supercool Machine Experience
With state-of-the-art, low-heat UV-LED lamps, and self-wicking ink features, the fully-enclosed LEF2-200 flatbed UV printer is simple-to-operate and runs clean and cool with a safeguarded operation. In addition to eliminating additional machine movements of previous models to give you a more efficient operation, it offers new machine advantages to streamline your print process.
Removes any ink remaining on the printheads and cleans the printhead surface to maintain the health and ink cost-efficiency of your printer.
Easily affix corner brackets to the print bed to simplify your set-up and the alignment of items for printing.
Nozzle Mask Function
If a nozzle on the printhead is clogged and misfiring, you can minimize printer downtime with the ability to turn off a specific nozzle band to allow continued production.
New Machine Panel Options
For efficient job set-up and operation, the machine menu now includes media height display, custom setting the origin point, and custom preset naming.
Start Timer Function
Automatically complete the setup operation of printhead cleaning and white ink circulation, so you can begin printing immediately after loading items— an auto wake-up feature acts like an alarm clock, alerting your LEF2-200 to start these cycling procedures.
Included VersaWorks 6
The latest edition features powerful new 64-bit processing and RIP capabilities, plus the easy cropping, tiling, nesting, and other advantages of the world’s most popular RIP software.
LED Pointer Set-Up
A new LED pointer precisely pinpoints the origin point of your print job.
|Roland Intelligent Pass Control
Controls dot placement between each pass for faster throughput and excellent image quality in all print modes.
An optional BOFA air filtration system ensures proper ventilation while also functioning as a stand and storage unit.
Get unattended, worry-free printing with e-mail or smart phone alerts that inform you of low ink or when a job has been completed.
An optional vacuum bed holds media perfectly steady to ensure print stability.
An optional machine attachment enables users to get better print results when printing on cylindrical objects.
|Printing method||Piezo ink-jet method|
|Attachable objects to be printed on||Width||Max. 21.2 in. (538 mm)|
|Length||Max. 14.2 in. (360 mm)|
|Thickness||Max. 3.94 in. (100 mm)|
|Weight||Max. 11 lb. (5kg)|
|Maximum printing width / printing length||Max. 20 (width) × 13 (length) in. (508 (width) × 330 (length) mm)|
|Ink||Type||ECO-UV (EUV, EUV4) 220 ml cartridge|
|Colors||Five colors (cyan, magenta, yellow, black, and white)
Five colors (cyan, magenta, yellow, black, and white) and primer
Six colors (cyan, magenta, yellow, black, white, and gloss)
|Ink-curing unit||Built-in UV-LED lamp|
|Print resolution (dots per inch)||Max. 1440 dpi|
|Distance accuracy*||Error of less than ±0.3% of distance traveled or ±11.8 mil (±0.3 mm), whichever is greater.|
|Connectivity||Ethernet (10BASE-T/100BASE-TX, automatic switching)|
|Power-saving function||Automatic sleep feature|
|Power requirements||AC 100 to 240 V ± 10%, 1.8 A, 50/60 Hz|
|Power consumption||During operation||Approx. 149 W|
|Sleep mode||Approx. 13 W|
|Acoustic noise level||During operation||60 dB (A) or less|
|During standby||49 dB (A) or less|
|Outer dimensions||47.3 [W] × 37.9 [D] × 21.6 [H] in. (1,202 (W) × 962 (D) × 549 (H) mm)|
|Weight||242.5 lb. (110 kg)|
|Environment||During operation||Temperature: 68 to 89.6°F (20 to 32°C) (71.6°F (22°C) or higher recommended),
Humidity: 35 to 80% RH (no condensation)
|Not operating||Temperature: 41 to 104°F (5 to 40°C), Humidity: 20 to 80% RH (no condensation)|
|Included items||Power cord, software RIP, cleaning liquid, drain bottle, manuals, etc.|
* Temperature: 25°C (77°F), Humidity: 50% RH
This device is capable of printing on a wide variety of substrates. However, the print quality or the ink adhesion may vary according to the substrate used and it is strongly recommended to test the substrate for compatibility to ensure optimal print results.
Vaporized components may slightly irritate the eyes, nose and/or throat during and following printing with this product. If continuously printing in a closed space, the density of volatile compositions will accumulate and may irritate the eyes, nose and /or throat. Roland DG strongly recommends that you install a ventilation system and use this product in a well-ventilated room. For more information, please contact your local distributor or dealer.
|Operating System||Windows® 10 (32/64-bit), Windows® 8.1 (32/64-bit), Windows® 7 Ultimate / Professional (32/64-bit)|
|CPU||Intel® Core™ 2 Duo, 2.0 GHz or faster recommended|
|RAM||2 GB or more recommended|
|Video card and monitor||A resolution of 1,280 x 1,024 or more|
|Free hard-disk space||40 GB or more recommended|
|Hard-disk file system||NTFS format|
|Other||Internet connection recommended|
|VersaUV LEF-12i||VersaUV LEF2-200||VersaUV LEF-300|
|Maximum Print Area||12" × 11"
305 mm × 280 mm
|20" × 13"
508 mm × 330 mm
|30" × 13"
770 mm × 330 mm
|Ink Configuration Options||CMYK + Clear (gloss) + White||
CMYK + Clear (gloss) + White
CMYK + Primer + White
CMYK + White + White
CMYK + Clear (gloss) + Clear (gloss)+ White
CMYK + Clear (gloss) + White+ Primer
|Included RIP Software||VersaWorks 6||VersaWorks 6||VersaWorks 6|
|Accessories||BOFA air filtration system (optional)
RotaPrint cylindrical printing attachment (optional)
Download the RotaPrint brochure (pdf)
|Ideal For||Short-run customization of USB drives, smart phone covers, photo frames and other small objects.||Short-run customization of small to medium-sized items, plus pre-primed printing onto various substrates and unique surfaces.||Volume production of small to medium-sized items, plus pre-primed printing onto various substrates and unique surfaces.|
|Explore LEF-12i||Explore LEF2-200||Explore LEF-300|
