Heavy Duty Performance, Beautiful Results

IU-1000F UV-LED High-Productivity Flatbed Printer

MSRP

Limited time only NOW $89,995 US*
WAS $99,995 US*
Get Promo
* Promotion valid through 06/30/2024 See promo page for terms and conditions.
LEASE PRICE

Limited time only NOW $1,827 US**
WAS $2,030 US**
Apply Now

** For 60 months, OAC

Quickly expand your output and rapidly grow the profitability of your sign business. Print high-quality graphics at incredible speeds directly onto 4’ x 8’ media boards with a 4.3-inch clearance.

Rapid, wide-pass, edge-to-edge printing on coroplast, acrylic, PETG, PVC board, foam board, wood, aluminum plate and so much more without loss of quality
Print 35 boards per hour and 280 boards a day with twelve printheads in a staggered formation— approximately 1,248.6 sq. ft. per hour in 4-color draft mode*
High-density, high-adhesion UV inks offer exceptional results on metal, glass, acrylic and more— print with industry-leading, high-opacity White ink with CMYK in a single pass

* Print speeds are based on average print test results for an average workday. Actual results may vary.

Play the IU-1000F video

The Ultimate in High-Volume,
High-Impact Print Production

Built tough for non-stop print production, you can build your sign and graphics business around the IU-1000F large format flatbed printer. Featuring high-resolution printing with banding prevention, twelve print heads, 1,280 nozzles per unit, and image results up-to 635 x 1,800 dpi, it offers fast, high-volume print production with high-impact graphic results.

Compatible with hundreds of substrates, ramp-up your UV printing speed, volume and profit.

**TRADESHOW DISPLAYS**
Print graphics with saturated color and detailed graphics directly onto 4’ x 8’ media boards and create large-format tradeshow signs and displays— add Gloss or Matte ink finishes with stylish 3D textures and embossed effects.

**SIGNAGE**
Print on 4’ x 8’ sheets of PVC board, corrugated board, foam board, banner material and create an industrial print solution for customizing high volumes of yard signs, store signs, POP displays and promotions. Add stylish 3D textures and embossed effects for a high-end look and feel.

**CUSTOM DIE-CUT SIGNS**
Combine your IU-1000F with a flatbed cutter to cut signs and create fun and exciting die-cut displays. Create original large format graphics for retail, hospitality, museum, exhibition and other industries with large format graphics applications.

**ACRYLIC, GLASS AND CERAMICS**
With high-adhesion UV ink, plus Primer ink options, easily prep and print on acrylic, glass and ceramic— adding graphics to challenging substrates and producing stand-out products like acrylic backlit displays.

**DÉCOR AND UNIQUE PRODUCTS**
Print onto sheets of aluminum, metal and wood for signs, décor, displays, print-to-cut prototypes, and other unique applications. Use Primer ink to prep your media and use double White ink configurations to get deep, rich color results.

**LEATHER, FABRIC AND CANVAS**
Add graphics to sheets of fabric, canvas and leather for high-volume banner, fabric displays, gallery and décor solutions— add brush strokes, textures and other artistic Gloss ink effects to art canvasses for unique fine art products.

See the IU-1000F high-productivity flatbed
printer in action!

Discover how you can achieve great adhesion and high color fidelity on a variety of substrates with the IU-1000F printer.

Print Speed and Quality
to Suit Your Production Needs

Featuring twelve high-performance inkjet printheads in a staggered three-row arrangement, the IU-1000F prints edge-to-edge on thin or thick boards. Meet fast turnaround times or produce high-end signs and displays with multiple speed and performance options.

BOARDS
AN HOUR

DRAFT MODE
(4-COLOR)

High-speed quality results for large format sign applications.

BOARDS
AN HOUR

STANDARD
MODE

Offers crisp and clear image definition on different media.

BOARDS
AN HOUR

QUALITY
MODE

For high end applications— achieve near-photographic quality results.

BOARDS
AN HOUR

DUAL WHITE INK
(STANDARD MODE)

Print CMYK and White layers at the same time for clear, consistent results on all substrates.

All print speeds displayed above are based on average print test results. Actual results may vary.

Ink Practicality, Versatility and Creativity

With the combination of White, Gloss, and Primer inks in addition to CMYK process colors, the IU-1000F offers high-end results on hundreds of applications.

Print high-opacity White ink with CMYK in a single pass to make colors really stand-out on dark and transparent media
Get excellent results on challenging substrates by prepping with Primer ink before printing your graphics
Add Gloss textures, raised embossed effects, and spot varnish for stunning finishes

Advanced Flatbed Technology
to Increase Production and Profit

Variable Dot Results

Variable dot technology simultaneously fires droplets of 5 pl (picoliters), 7 pl, and 15 pl, to create high-definition images, smooth gradations, and solid color output.

Small Droplets and
Low-Running Costs

Reduce flatbed running costs with small droplet printing that limits ink consumption and UV-LED lamps that save energy and lengthen lamp life.

Easy Media Handling
and Print Stability

A variable zone vacuum can be applied to four different sections of the flatbed to maximize air suction in specific areas— enabling easy media loading and print stability when handling media.

Media Alignment Pins

Get consistent media placement of multiple boards and double-sided panels with media alignment pins in the corners of the flatbed that pop-up at the touch-of-a-button for automatic print alignment to the origin point.

Productivity Features

	Easily manage your machines movements, speed, voltage, head cleaning and more from your desktop with the Roland DG Print Control Center.
	Includes a premium RIP software package with intuitive tiling, scaling, cropping and many more essential features.
	Offers a smooth operation and performance with one-touch, automated daily printhead cleaning— avoid losing valuable print time.

	Low odor, low chemical emission inks and a “human proximity sensor” create a safe machine environment for flatbed operators.
	Features a media ionizer to reduce static and ensure ink-firing accuracy on materials like corrugated boards that generate a lot of static.
	Print one large board or print on multiple boards at the same time with the production versatility of the IU-1000F.

Built to Build Your Business with Industry Best Warranty, Service and Support

Roland DGA offers a higher standard of machine reliability, combined with a superior level of service and support. Your IU-1000F UV-LED industrial flatbed printer is also supplied with a Two-Year Trouble-Free Warranty to give you added machine security and peace-of-mind.

* Registration within 60 days of purchase and exclusive, continuous use of Roland DG approved inks is required to qualify for the second year of warranty coverage.

Additional Information

Expand All | Collapse All

Sample Request

To receive a free print sample from the IU-1000F , complete the form below and click Submit.

Specifications

IU-1000F
Printing method		Piezo ink-jet method
Media	Maximum size	98.8 × 51.5 in. (2,510 × 1,310 mm)
	Maximum thickness	4.33 in. (110 mm)
	Maximum weight	99 lbs/m² (45 kg/m²)
Maximum printing area		98.4 (width) × 51.1 (length) in. (2,500 × 1,300 mm)
Ink	Type	UV Curable Ink (UE, US)
	Color	Six colors (cyan, magenta, yellow, black, white, and gloss) and primer
	Ink bottle capacity	CY, MG, YE, BK, GL, PR: 1,000 ml WH: 900 ml (US-WH), 850 ml (UE-WH)
	Ink tank capacity	2,500 ml per color
Ink curing unit		UV-LED lamp
Print resolution (dots per inch)		Max. 635 × 1,800 dpi
Media vacuum system		Up to four vacuuming areas with adjustable vacuum pressure
Connectivity		USB 3.0
Power requirements		EMEA 25A 3-phase 400 V NA/JPN 30A 3-phase 220 V
Dimensions		189.4 (W) × 86.6 (D) × 62.2 (H) in. (4,812 × 2,200 × 1,580 mm)
Weight		3,166 lb (1,436 kg)
Environment	Temperature	59 to 86 °F (15 to 30 °C)
Environment	Humidity	40 to 80 %
Included items		USB cable, paper towel, cleaning kit, CD manuals, software installation CD, etc.
Acoustic noise level		75 dB (A) or less

This device is capable of printing on a wide variety of substrates. However, the print quality or the ink adhesion may vary according to the substrate used and it is strongly recommended to test the substrate for compatibility to ensure optimal print results.

Software System Requirements
Print control (bundled)	OS	Windows® 7/10 (64 bit)
	CPU	Intel® Core™ i5, 2 GHz or more
	RAM	8 GB or more
	Video card and monitor	A resolution of 1,152 × 854 with 16 bit color or higher
	HDD	Install space 1 GB or more Working space 100 GB

Brochure

Download Your IU-1000F Brochure

Get your digital guide to all the features, applications, benefits and specifications of the UV-LED High-Productivity Flatbed Printer.

Download Brochure
