IU-1000F UV-LED High-Productivity Flatbed Printer | Roland DGA
Heavy Duty Performance, Beautiful Results

NEW IU-1000F UV-LED High-Productivity Flatbed Printer

  • LIST PRICE

    $149,995

    U.S. only. For Canada, Latin America and Caribbean pricing, please contact an Authorized Roland Dealer in your area. Price subject to change.

    Price includes machine installation and training.

  • LEASE PRICE

    $3,000 US **

    ** For 60 months, OAC

    Financial Services

Print high quality graphics at incredible speeds directly onto 4' x 8' media boards with a 4.3-inch height clearance.

  • Print on PETG, PVC board, foam board, wood, corrugated board, aluminum plate and so much more.
  • Rapid, wide-pass printing with twelve printheads in a staggered three-row arrangement— prints approximately 1,248.6 sq. ft. per hour in 4-color draft mode.
  • High-density, high-adhesion UV inks for full-color printing onto metal, glass and acrylic— includes Primer ink for added adhesion.



Request a Dealer

The Ultimate in High-Volume,
High-Impact Print Production

Built tough for non-stop print production, you can build your sign and graphics business around the IU-1000F large format flatbed printer. Featuring high-resolution printing with banding prevention, twelve print heads, 1,280 nozzles per unit, and image results up-to
635 x 1,800 dpi, it offers fast, high-volume print production with high-impact graphic results.

Compatible with hundreds of substrates, ramp-up your UV printing speed, volume and profit.

IU-1000F printhead

Print Speed and Quality
to Suit Your Production Needs

Featuring twelve high-performance inkjet printheads in a staggered three-row arrangement, the IU-1000F prints edge-to-edge on thin or thick boards. Meet fast turnaround times or produce high-end signs and displays with multiple speed and performance options.

Standard configuration
Standard configuration
Double White configuration
Double White configuration
35
BOARDS
AN HOUR

DRAFT MODE
(4-COLOR)


High-speed quality results for large format sign applications.

15
BOARDS
AN HOUR

STANDARD
MODE


Offers crisp and clear image definition on different media.

10
BOARDS
AN HOUR

QUALITY
MODE


For high end applications— achieve near-photographic quality results.

6
BOARDS
AN HOUR

DUAL WHITE INK
(STANDARD MODE)


Print CMYK and White layers at the same time for clear, consistent results on all substrates.



All print speeds displayed above are based on average print test results. Actual results may vary.

Multi-Layered Printing in a Single Pass
Multi-Layered Printing in a Single Pass

Ink Practicality, Versatility and Creativity

With the combination of White, Gloss, and Primer inks in addition to CMYK process colors, the IU-1000F offers high-end results on hundreds of applications.

  • Print high-opacity White ink with CMYK in a single pass to make colors really stand-out on dark and transparent media
  • Get excellent results on challenging substrates by prepping with Primer ink before printing your graphics
  • Add Gloss textures, raised embossed effects, and spot varnish for stunning finishes

Productivity Features

Easily manage your machines movements, speed, voltage, head cleaning and more from your desktop with the Roland Print Control Center.
Includes a premium RIP software package with intuitive tiling, scaling, cropping and many more essential features.
Offers a smooth operation and performance with one-touch, automated daily printhead cleaning— avoid losing valuable print time.
Low odor, low chemical emission inks and a “human proximity sensor” create a safe machine environment for flatbed operators.
Features a media ionizer to reduce static and ensure ink-firing accuracy on materials like corrugated boards that generate a lot of static.
Print one large board or print on multiple boards at the same time with the production versatility of the IU-1000F.

Additional Information

IU-1000F
Printing method Piezo ink-jet method
Media Maximum size 98.8 × 51.5 in. (2,510 × 1,310 mm)
Maximum thickness 4.33 in. (110 mm)
Maximum weight 99 lbs/m2 (45 kg/m2)
Maximum printing area 98.4 (width) × 51.1 (length) in. (2,500 × 1,300 mm)
Ink Type UV Curable Ink (UE, US)
Color Six colors (cyan, magenta, yellow, black, white, and gloss) and primer
Ink bottle capacity CY, MG, YE, BK, GL, PR: 1,000 ml
WH: 900 ml (US-WH), 850 ml (UE-WH)
Ink tank capacity 2,500 ml per color
Ink curing unit UV-LED lamp
Print resolution (dots per inch) Max. 635 × 1,800 dpi
Media vacuum system Up to four vacuuming areas with adjustable vacuum pressure
Connectivity USB 3.0
Power requirements EMEA 25A 3-phase 400 V
NA/JPN 30A 3-phase 220 V
Dimensions 189.4 (W) × 86.6 (D) × 62.2 (H) in. (4,812 × 2,200 × 1,580 mm)
Weight 3,166 lb (1,436 kg)
Environment Temperature 59 to 86 °F (15 to 30 °C)
Humidity 40 to 80 %
Included items USB cable, paper towel, cleaning kit, CD manuals, software installation CD, etc.
Acoustic noise level 75 dB (A) or less

This device is capable of printing on a wide variety of substrates. However, the print quality or the ink adhesion may vary according to the substrate used and it is strongly recommended to test the substrate for compatibility to ensure optimal print results.

Software System Requirements
Print control
(bundled)
OS Windows® 7/10 (64 bit)
CPU Intel® Core™ i5, 2 GHz or more
RAM 8 GB or more
Video card and monitor A resolution of 1,152 × 854 with 16 bit color or higher
HDD Install space 1 GB or more
Working space 100 GB
