More Flexibility, More Opportunity
VersaOBJECTNEW CO Series UV Flatbed & Hybrid Printers
* U.S. only. For Canada, Latin America and Caribbean pricing, please contact an Authorized Roland DGA Dealer in your area.
** For 60 months, OAC
Take object customization to new heights with the VersaOBJECT CO Series of UV flatbed printers. Digital UV printing has never been more versatile and the CO Series is the perfect solution for customizing boards, objects up to 7.87 in height and even irregular 3D objects.
- Premium quality direct-to-object or substrate printing
- Special effect printing for added-value products
- High-volume object customization and personalization
- Available in a size and configuration to suit your business
Flatbed UV Printing Solutions
The Ultimate in Versatile Print Production
Deliver high-quality vibrant and impactful graphics onto a vast range of objects and substrates, including metal, plastic, board, wood, canvas, vinyl, paper and much more besides, accommodating material up to 200 mm height.
Optional Rotary Rack XL & XXL
The Rotary Rack XL and XXL were created to add versatility to Roland DG UV flatbed printers by giving users the ability to print on the entire circumference of cylindrical objects such as insulated water bottles, glass vases and candles, drum sticks, shot glasses and a wide variety of objects ranging from 0.5 inch to 7.75 inches in diameter.
ECO-UV5 inks are GREENGUARD Gold certified, meaning they meet strict standards of low chemical emissions, making them ideal for indoor applications.
Choose an CO Series Printer
That Fits Your Business
The CO Series offers machine options that reflect the products and media choices you want to print on. We provide two different carriage sizes and six different bed size options, including our full-sized model that prints on full-boards and an optional belt-driven model that solves space issues and prints roll-to-roll as well as rigid.
VersaOBJECT CO Series
Impressive Height and Weight Capabilities
Offering extraordinary application versatility, the CO Series can print on objects up to 7.87 inches in height and up to 2373 lb/ft2 in weight.
The CO Series flatbed UV printers feature an innovative Distance Mode. This makes it possible to print White and CMYK inks onto convex, concave or irregular surfaces whilst maintaining excellent quality and sharpness.
Print Large Quantities of Smaller Items
Improve your productivity with a fast and efficient direct-to-object printing solution. The CO Series lets you print unique details on several items in a single print run and with VersaWorks 6 features like variable data printing, you can individually personalize each item quickly and with minimal set-up.
Safety Control Features
An emergency stop perimeter around base (and on the side of the device) safeguards operators in the busiest of production environments. Plus, there is a signal beacon with variable alerts to clearly highlight the printer status.
Low-Temperature Adjustable UV-LED lamps
Intensity of the
Print onto a virtually limitless range of flexible and rigid substrates and objects.
The vacuum bed operates quietly and features a reverse blow setting that removes material from the bed for clean and efficient production.
Print directly onto irregular or curved objects with a high degree of accuracy.
Create an easy and safe operator area with a separate control tower with touch panel controls.
Match your customers' color with ease thanks to advanced RIP features.
Long-life print heads and ink-clogging prevention ensures long life and sustained quality.
Add extra expression to your prints easily with a library full of exciting printable textures.
Plug in and start working immediately thanks to Roland DG’s user-friendly interface.
Multifunctional RIP Software Included
Multifunctional RIP Software Included
Besides its high-speed RIP functionality, VersaWorks 6 RIP includes a wide selection of productivity-boosting features for the CO Series.
- HARLEQUIN RIP dual core engine and 64-bit native processing for enhanced speed and file handling.
- Variable data options for printing multiple images and text onto media in a single print run.
- UV post cure within the RIP and auto-generate White and Gloss layers directly in the RIP with Special Color Plate Generation.
- Create cut data directly in VersaWorks 6 by extracting PDF data from your design file to use as a cut line — changing vector data into cut line data, merging multiple cut lines together, creating perf cut lines, and other intuitive features.
- Easy new drag-and-drop interface allows you to quickly add jobs to the print queue.
- Create color consistency with select Roland DG devices— print, scan and transfer color values.
- Rotate, set spacing, and maintain clip position within the RIP to give you more control when printing graphics and applying Gloss ink effects.
- Customize larger quantities of unique items using the built-in Variable Data functionality.
Roland DG Connect App
For Everything Creative
Reduce downtime and improve work efficiency with a machine monitoring assistant that helps you gain a detailed understanding of your entire print operation while keeping your device running at optimum performance.
Create Value with Direct Printing
Introducing VersaOBJECT from Roland DG - a comprehensive solution that enable anyone to easily print directly onto 3D objects made of a variety of materials.
Roland DGA’s Industry-Leading Warranty and Support
Roland DG has provided industry professionals with the highest quality products for more than 40 years, backed by unmatched customer service and support. For even greater peace of mind, every VersaOBJECT series device is supplied with a Two-Year Trouble-Free Warranty.*
* Registration within 60 days of purchase and exclusive, continuous use of Roland DG approved inks is required to qualify for the second year of warranty coverage.
|Model||CO-300-F200 (Flatbed)||CO-640-F200 (Flatbed)||CO-640-F300 (Flatbed)||CO-640-F400 (Flatbed)||CO-300-B200 (Belt)||CO-640-B200 (Belt)|
|Printing Method||Piezo ink-jet method|
|Acceptable Media||Width||30 in.
|Thickness/Height||0.0004 in. to 7.87 in.
(0.01 to 200 mm)
|Weight Bed||20 lb./ft2
(100 kg / m2)
|Bed Size||32 (W) x 81 (D) in.
[820 (W) x 2,050 (D) mm]
|66.5 (W) x 81 (D) in.
[1,690 (W) x 2,050 (D) mm]
|66.5 (W) x 121 (D) in.
[1,690 (W) x 3,065 (D) mm]
|66.5 (W) x 143 (D) in.
[1,690 (W) x 3,625 (D) mm]
|31 (W) x 69 (D) in.
[775 (W) x 1,750 (D) mm]
|65 (W) x 69 (D) in.
[1,648 (W) x 1,750 (D) mm]
|Maximum Printing Width/Length||29 (W) x 59 (L) in.
[749 (W) x 1,500 (L) mm]
|63 (W) x 59 (L) in.
[1,612 (W) x 1,500 (L) mm]
|63 (W) x 98 (L) in.
[1,612 (W) x 2,500 (L) mm]
|63 (W) x 120 (L) in.
[1,612 (W) x 3,050 (L) mm]
|29 (W) x Unlimited (L) in.
[749 (W) x Unlimited (L) mm]
|63 (W) x Unlimited (L) in.
[1,612 (W) x Unlimited (L) mm]
||Types||ECO-UV（EUV5） 220 ml cartridge（White）
ECO-UV（EUV5） 500 ml cartridge（Cyan, Magenta, Yellow, Black, Red, Orange, Gloss, Primer）
Eight colors (Cyan, Magenta, Yellow, Black, Red, Orange, White, Gloss)
Eight colors (Cyan, Magenta, Yellow, Black, Red, Orange, White）
Seven colors (Cyan, Magenta, Yellow, Black, Red, Orange, White) and Primer
Seven colors (Cyan, Magenta, Yellow, Black, Red, White, Gloss) and Primer
Six colors (Cyan, Magenta, Yellow, Black, White, Gloss) and Primer
Six colors (Cyan, Magenta, Yellow, Black, White, Gloss）
Four colors (Cyan, Magenta, Yellow, Black)
|Printing Resolution (dpi)||Max. 1,440 dpi|
|Movement Method||High resolution stepping motor|
|Output modes||Continuous, unload, return to origin, layered|
|Media Height Setting||Manual, auto sensor|
|Surface Control||Manual, auto sensor|
|Control Interface (tower)||7" Color LCD touch screen|
|Interface||Ethernet Base 10/100|
|Power-saving Function||Automatic sleep feature|
|Power Requirements||230V 16A 2P+E|
|Power Consumption||Print with 100% Vacuum||1.45 kw||1.45 kw||2.65 kw||2.65 kw||1.45 kw||2.65 kw|
|Acoustic Noise Level||Print with Vacuum||< 70 dB|
|During Standby||< 40 dB|
|Dimensions||Printer Unit*1||76 (W) x 83 (D) x 59 (H) in.
[1,928 (W) x 2,109 (D) x 1,490 (H) mm]
|111 (W) x 83 (D) x 59 (H) in.
[2,815 (W) x 2,109 (D) x 1,490 (H) mm]
|111 (W) x 123 (D) x 59 (H) in.
[2,815 (W) x 3,126 (D) x 1,490 (H) mm]
|111 (W) x 143 (D) x 59 (H) in.
[2,815 (W) x 3,635 (D) x 1,490 (H) mm]
|76 (W) x 78 (D) x 59 (H) in.
[1,928 (W) x 1,983 (D) x 1,490 (H) mm]
|111 (W) x 78 (D) x 59 (H) in.
[2,815 (W) x 1,983 (D) x 1,490 (H) mm]
|Control Tower||21 (W) x 21 (W) x 43 (H) in.
[530 (W) x 530 (D) x 1,080 (H) mm]
|Weight (kg)||450 + 50 kg (Control tower)||600 + 50 kg (Control tower)||800 + 50 kg (Control tower)||950 + 50 kg (Control tower)||590 + 50 kg (Control tower)||815 + 50 kg (Control tower)|
|Weight Distribution||6 points - 6 feet (80 mm diameter)||6 points - 6 feet (80 mm diameter)||8 points - 8 feet (80 mm diameter)||10 points - 10 feet (80 mm diameter)||6 points - 6 feet (80 mm diameter)||6 points - 6 feet (80 mm diameter)|
|Environment||Power On||Temperature: 20 to 32ºC (68 to 90ºF) (22ºC [72ºF] or more recommended), Relative humidity: 35 to 80% (no condensation)|
|Power Off||Temperature: 5 to 40ºC (41 to 104ºF), Relative humidity: 20 to 80% (no condensation)|
|Included accessories||RIP Software, User Manual, Power Cable, Cleaning Kit, Installation Toolbox|
1Due to vertical capacity of printer, device height will vary based on media being printed. Please ensure you have sufficient vertical space above printer.
|VersaWorks 6 System Requirements|
|Operating System||Windows® 10 (32/64 bit), Windows® 8.1 (32/64 bit), Windows® 7 Ultimate/Professional (32/64 bit)|
|Hard-disk file system||NTFS Format|
|CPU||Intel Core™ 2 Duo, 2.0 GHz or faster recommended|
|RAM||2GB or more recommended|
|Video card and monitor||A resolution of 1280 x 1024 or more recommended|
|Free hard disk space||40 GB or more recommended|
|Ethernet Connection||100 mbps|
|Other||Internet connection recommended|
